5 - 5DigiGate-700
™
for Windows
®
- User’s Guide
DigiGate-700
for Windows
™ ®
9. This opens the
Select Directory
window. Figure 5-5
10. Navigate to the directory the backup
should be saved to.
11. Click on the
OK
button.
12. This returns to the
Backup
window.
Figure 5-6
13. Click on the
Backup
button.
NOTE: The program writes the backup
Zip file to the selected directory with the
name
Digitech International
Inc.{yyyymmdd}.zip
where
{yyyymmdd} is the date the file is saved.
14. When the operation completes, the
Utility
Menu
window is activated.
15. Click on the
Close
button to return to the
System Toolbar
.
Figure 5-5
Figure 5-6
